Inverter Protocol Choosing
Use DIP address to set the RS485 baud rate and inverter protocol choosing
Communications
Canbus : Victron,SMA,Studer Innotec,Sofar,Solark,Solis,Goodwe,Deye,
Growatt,SAJ,LUXPOWER,Megarevo,INVT,Sermatec,TBB,
MUST,Sunsynk,Schneider
RS485 : MPP,Voltronic,RCT,Alpha outback
Standard Included
(1) RUiXU 48V Server Rack battery (RX-LFP48100)
(1) RS485 Communication Cable
(1) Ground Cable
(1) Set of Parallel 4AWG Cables per battery
RX-LFP48100-H
Nominal voltage :51.2V
Nominal capacity@0.2C :100 Ah
Min. capacity@0.2C:100 Ah
Nominal energy :5120Wh
Dimesion(W*D*H):482.6x460x133mm | 19 x 18.1 x 5.23 inch
Weight: ~47kg (103.6lb)
Specification
RUiXU RX-LFP48100-H 19" Rack Mounted 3U Module Self-heating LiFePO4 Battery Specification
User Manual
RUiXU RX-LFP48100-H 19" Rack Mounted 3U Module Self-heating LiFePO4 Battery User Manual
